Tubing

İnert akış yolları gerektiren prosesler için PTFE ve FEP boru ürünleri ve aksesuarları.

Ham PTFE ve FEP Boru

Part # / Ref #	Description
20907	7 Gauge Custom PTFE Tubing
20908	8 Gauge Custom PTFE Tubing
20909	9 Gauge Custom PTFE Tubing
20910	10 Gauge Custom PTFE Tubing
20911	11 Gauge Custom PTFE Tubing
20912	12 Gauge Custom PTFE Tubing
20913	13 Gauge Custom PTFE Tubing
20914	14 Gauge Custom PTFE Tubing
20915	15 Gauge Custom PTFE Tubing
20916	16 Gauge Custom PTFE Tubing
20917	17 Gauge Custom PTFE Tubing
20918	18 Gauge Custom PTFE Tubing
20919	19 Gauge Custom PTFE Tubing
20920	20 Gauge Custom PTFE Tubing
20922	22 Gauge Custom PTFE Tubing
20924	24 Gauge Custom PTFE Tubing
20926	26 Gauge Custom PTFE Tubing
20928	28 Gauge Custom PTFE Tubing
20930	30 Gauge Custom PTFE Tubing
20937	FEP Tubing 18 gauge (.074″ O.D. / .042″ I.D.) over 10′ (specify length)
20938	FEP Tubing 12 gauge (.117″ O.D. / .085″ I.D.) over 10′ (specify length)
20939	Teflon-FEP Tubing 22 gauge (.074″ O.D. / .028″ I.D.) over 10′ (specify length)
20941	1/8″ Gauge Custom PTFE Tubing (1/8″ ID x .015″ Wall)
20942	1/16″ Gauge Custom PTFE Tubing (1/16″ ID x .030″ Wall)
20943	1/32″ Gauge Custom PTFE Tubing (1/32″ x .016″ Wall)
32903	Tubing Holder
88906	FEP Tubing 22 gauge (.074″ O.D. / .028″ I.D.) 10’/pk
88907	FEP Tubing 18 gauge (.074″ O.D. / .042″ I.D.) 10’/pk
88908	FEP Tubing 12 gauge (.117″ O.D. / .085″ I.D.) 10’/pk
88922	PTFE 1/8″ Tubing 10ft (O.D. 0.125″ / I.D. 0.063″)

Havşalı Borular için Bağlantı Elemanları ve Rondelalar

Part # / Ref #	Description
249922	M6 Washer (22/18 ga.) 1/pk
249924	M6 Washer (12 ga.) 1/pk
32806	1/4-28 Fitting (22/18 ga.) 1/pk
32807	1/4-28 Fittings (12 ga.) 1/pk
32857	M6 Fitting (1/8″ O.D.) 1/pk
32882	1/4-28 Washer (22/18 ga.) 1/pk
32883	1/4-28 Washer (12 ga.) 1/pk
88806	1/4-28 Fittings and Washers (22/18 ga.) 10/pk
88807	1/4-28 Fittings and Washers (12 ga.) 10/pk
88856	M6 Fittings and Washers (1/16″ O.D.) 10/pk
88857	M6 Fittings and Washers (1/8″ O.D.) 10/pk
88882	1/4-28 Washer (22/18 ga.) 10/pk
88883	1/4-28 Washers (12 ga.) 10/pk

Flanşlama Alet Kiti

Part # / Ref #	Description
32905	Flanging Tip 22 gauge
32906	Flanging Tip 18 gauge
32907	Flanging Tip 12 gauge
88821	Flanging Tool Kit 120V

1/4″-28 Boru Tertibatları

Part # / Ref #	Description
37952	Two Hubs Assembled with 9″ of Tubing (12 gauge)
39103	One Hub Assembled with 25.5″ of Tubing (12 gauge)
88900	Two Hubs Assembled with Custom Length Tubing (O.D. 0.063″ / I.D. 0.042″)
88901	Two Hubs Assembled with Custom Length Tubing (O.D. 0.063 / I.D. 0.042) with Strain Relief
88902	Two Hubs Assembled with Custom Length Tubing (O.D. 0.063 / I.D. 0.031)
88910	Two Hubs Assembled with Custom Length Tubing (O.D. 0.125″ / I.D. 0.09″)
88912	Two Hubs Assembled with Custom Length Tubing (O.D. 0.125″ / I.D. 0.063″)
88913	Two Hubs Assembled with Custom Length Tubing (O.D. 0.125″ / I.D. 0.063″) with Strain Relief
88916	Two Hubs Assembled with 12″ of Tubing (22 gauge)
88917	Two Hubs Assembled with 12″ of Tubing (18 gauge)
88918	Two Hubs Assembled with 12″ of Tubing (12 gauge)
88939	One Hub Assembled with 30″ of Tubing (18 gauge)
88942	One Hub Assembled with 30″ Tubing (12 gauge)
88946	Two Hubs, IS/IS Thread 22 ga. / 25″
88947	Two Hubs, IS/IS Thread 18 ga. / 25″
88948	Two Hubs, IS/IS Thread (12 ga.) 25″
88950	Two Hubs, IS/IS Thread 25″ Light Wall 1/16″ O.D. .042″ I.D.
88952	Two Hubs, IS/IS Thread 25″ Heavy Wall 1/16″ O.D. 1/32″ I.D.
88956	Two Hubs, IS/HV Thread 22 ga. / 12″
88957	Two Hubs, IS/HV Threads 18 ga. / 12″
88958	Two Hubs, IS/HV Threads 12 ga. / 12″
88960	Two Hubs, IS/IS Thread 25″ Light Wall 1/8″ O.D. / .095″ I.D.
88962	Two Hubs, IS/IS Thread 25″ Heavy Wall 1/8″ O.D. 1/16 I.D.
88986	One Hub Assembled with 24″ of Tubing (22 gauge)
88987	One Hub Assembly with 24″ of Tubing (18 gauge)
88988	One Hub Assembled with 24″ of Tubing (12 gauge)

Dişi Luer Kilitli Boru Tertibatları

Part # / Ref #	Description
86510	Two Hubs Assembled with Custom Length and Gauge
90607	One Hub Assembled with 12″ of Tubing (7 gauge)
90608	One Hub Assembly with 12″ of Tubing (8 gauge)
90609	One Hub Assembly with 12″ of Tubing (9 gauge)
90610	One Hub Assembled with 12″ of Tubing (10 gauge)
90611	One Hub Assembled with 12″ of Tubing (11 gauge)
90612	One Hub Assembled with 12″ of Tubing (12 gauge)
90613	One Hub Assembled with 12″ of Tubing (13 gauge)
90614	One Hub Assembled with 12″ of Tubing (14 gauge)
90615	One Hub Assembled with 12″ of Tubing (15 gauge)
90616	One Hub Assembled with 12″ of Tubing (16 gauge)
90617	One Hub Assembled with 12″ of Tubing (17 gauge)
90618	One Hub Assembled with 12″ of Tubing (18 gauge)
90619	One Hub Assembled with 12″ of Tubing (19 gauge)
90620	One Hub Assembled with 12″ of Tubing (20 gauge)
90622	One Hub Assembled with 12″ of Tubing (22 gauge)
90624	One Hub Assembled with 12″ of Tubing (24 gauge)
90626	One Hub Assembled with 12″ of Tubing (26 gauge)
90628	One Hub Assembled with 12″ of Tubing (28 gauge)
90630	One Hub Assembled with 12″ of Tubing (30 gauge)
90641	One Hub Assembled with 12″ of Tubing (1/8″)
90657	One Hub Assembled with Custom Length Tubing (7 gauge)
90658	One Hub Assembled with Custom Length Tubing (8 gauge)
90659	One Hub Assembled with Custom Length Tubing (9 gauge)
90660	One Hub Assembled with Custom Length Tubing (10 gauge)
90661	One Hub Assembled with Custom Length Tubing (11 gauge)
90662	One Hub Assembled with Custom Length Tubing (12 gauge)
90663	One Hub Assembled with Custom Length Tubing (13 gauge)
90664	One Hub Assembled with Custom Length Tubing (14 gauge)
90665	One Hub Assembled with Custom Length Tubing (15 gauge)
90666	One Hub Assembled with Custom Length Tubing (16 gauge)
90667	One Hub Assembled with Custom Length Tubing (17 gauge)
90668	One Hub Assembled with Custom Length Tubing (18 gauge)
90669	One Hub Assembled with Custom Length Tubing (19 gauge)
90670	One Hub Assembled with Custom Length Tubing (20 gauge)
90672	One Hub Assembled with Custom Length Tubing (22 gauge)
90674	One Hub Assembled with Custom Length Tubing (24 gauge)
90676	One Hub Assembled with Custom Length Tubing (26 gauge)
90678	One Hub Assembled with Custom Length Tubing (28 gauge)
90680	One Hub Assembled with Custom Length Tubing (30 gauge)
90691	One Hub Assembled with Custom Length Tubing (1/8″)

Boru Ölçüleri

	Nominal O.D.		Nominal I.D.
Gauge	inch	mm	inch	mm	Wall Thickness (in.)	Volume µL/inch
30	0.03	0.76	0.012	0.3	0.009±0.002	2.17
28	0.033	0.84	0.015	0.38	0.009±0.002	2.88
26	0.036	0.91	0.018	0.46	0.009±0.002	4.22
24	0.04	1.02	0.022	0.56	0.009±0.002	6.26
22	0.046	1.17	0.028	0.71	0.009±0.002	9.5
20	0.058	1.47	0.034	0.86	0.012±0.003	14.75
19	0.062	1.57	0.038	0.97	0.012±0.003	18.77
18	0.066	1.68	0.042	1.07	0.012±0.003	22.84
17	0.071	1.8	0.047	1.19	0.012±0.003	28.25
16	0.077	1.96	0.053	1.35	0.012±0.003	36.36
15	0.083	2.11	0.059	1.5	0.012±0.003	44.89
14	0.09	2.29	0.066	1.68	0.012±0.003	56.3
13	0.1	2.54	0.076	1.93	0.012±0.003	74.31
12	0.109	2.77	0.085	2.16	0.012±0.003	93.07
11	0.119	3.02	0.095	2.41	0.012±0.003	115.87
10	0.13	3.3	0.106	2.69	0.012±0.003	143.28
9	0.148	3.76	0.118	3	0.015±0.004	179.54
8	0.163	4.14	0.133	3.38	0.015±0.004	227.91
7	0.178	4.52	0.148	3.76	0.015±0.004	282.03
1/8	0.155	3.94	0.125	3.18	0.015±0.004	201.73
